Electroacoustic specs
2-way passive enclosure
amplified by LA2Xi / LA4X / LA8 / LA12X
| Usable bandwidth (-10 dB) | 87 Hz – 20 kHz ([SYVA]) |
| Maximum SPL1 | 137 dB ([SYVA]) |
| Nominal directivity (-6 dB) | vertical: +5°/-21° |
| Transducers | MF: 6 × 5″ cone drivers |
| Acoustical load | LF: bass-reflex, L-Vents |
| Nominal impedance | 8 Ω |
1 Peak level measured at 1 m under free field conditions using pink noise with crest factor 4 (preset specified in brackets).
Physical specs
| Connectors | 1 x 4-point speakON |
| Rigging and handling | DIN580-compatible M8 threaded insert |
| Dimensions | 144 mm (5.7 in) / 1301 mm (51.2 in) 209 mm (8.2 in) |
| Weight (net) | 21 kg / 46 lb |
| Cabinet | premium grade Baltic beech and birch plywood |
| Front | Coated steel grill |
| Finish | dark grey brown Pantone 426 C |
| IP | IP54 |
