LA7.16
Multi-channel amplified controller
| Architecture | 16 x 16 |
| Output Power |
16 x 700 W at 16 ohms 16 x 1300 W at 8 ohms 16 x 1100 W at 4 ohms |
| Power supply | Universal SMPS with PFC |
| Inputs | Milan-AVB, AES/EBU, Analog |
| Network | Milan-certified with seamless network redundancy |
Inspiration
Garth Brooks’ Friends In Low Places Bar & Honky-Tonk Dazzles “Other” Broadway with L-Acoustics and DiGiCo
A10i Focus
A10i Wide
A15i
KS21
LA4X
LA7.16
X8
The Other Side is the World’s First Nightclub to Adopt L-ISA Spatial Audio
A15
A15 Focus
A15 Wide
KS21
L-ISA
L-ISA Controller
LA4X
LA7.16
X12
X8
L-ISA Immersive Audio Experience Brings the Ancient Ephesus Experience to Life
5XT
A10
KS21
L-ISA
LA7.16
X8
Related Products
Related Trainings
Need more information?
Check out our Documentation Center for more documents on this product.
Amplification and power supply
| Amplification class | High-efficiency class D |
| Output power, all channels loaded | 16 x 1100 W at 4 ohms 16 x 1300 W at 8 ohms 16 x 700 W at 16 ohms |
| nominal power requirements | 16 A (200-240 V) 30 A (100-120 V) |
| mains connector | 32 A powerCON |
| Power supply model | Universal Switched Mode Power Supply (SMPS) with Power Factor Correction (PFC) |
| Mains rating | 100 V - 240 V ±10%, 50-60 Hz |
| External DSP backup voltage input | 24 V DC |
DSP
| Digital Signal Processor (DSP) | Gen.5 Dual SHARC 32-bit, floating point, 96 kHz sampling rate |
| I/O routing | 16 x 16 routing and summation matrix |
| Per output channel | Built-in EQ station with 8 IIR, 4 FIR linear phase EQ filters Array morphing (LF contour, zoom factor), Air absorption compensation filters Internal IIR and FIR EQ algorithms for speaker phase linearization and improved impulse responses Output delay from 0 to 1000 ms |
Technologies
| loudspeaker management | L-DRIVE advanced system protection |
| amplifier management | L-SMART adaptative power management |
Latency
| standard latency (analog/digital inputs) | 3.84 ms |
| low latency (analog/digital inputs) | 1.18 ms |
Inputs
| Milan-AVB | 16 channels from up to 16 streams (of up to 8 channels each) |
| AES/EBU | 2 channels AES/EBU (1 x AES3) with SRC |
| analog | 1 channel analog |
| connections | 2 etherCON 1 Gb/s I/O+ control 1 male 12-point terminal block (AES3 or Ana input/link + GPIO) |
Outputs
| loudspeaker connections | 1 SC32 connector |
Circuits protection
| Mains and power supply | Over and under voltage / over temperature / overcurrent |
| Power outputs | Overcurrent / DC / short circuit / over temperature |
Interface
| display/indicators | 1 TFT color touchscreen display (480 × 128 px) |
| Display | 1 encoding wheel with push button |
Remote control and monitoring
| L-Acoustics remote control software | LA Network Manager |
| General purpose inputs and outputs (GPIO) | 3 in/out on 12 point terminal block |
| Third-party management solutions | Q-SYS® / Crestron® |
Operating conditions
| Temperature | -5º C / 23º F to +50º C / 122º F |
Physical data
| Height | 2U |
| Weight | 15.8 kg / 34.8 lb |
Dimensions
